post #211 of 263 (permalink) Old 05-20-2019, 03:19 PM
Senior Member
FFCars Craftsman

jhargrove's Avatar

Join Date: Feb 2018
Location: Aurora, Il
Posts: 691
I used a transmission jack. This worked perfect I ended up leaving it on the jack for awhile too.

I was able to install it by myself and line everything up to easily. The jack will make putting the transmission on the engine easier too.

I suggest renting or buying one if you have to do that again and or need to put a transmission on.

Jason

jhargrove is online now
Sponsored Links
Advertisement

post #212 of 263 (permalink) Old 05-20-2019, 04:31 PM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
yes, transmission jack would have been much easier that a floor jack.
we had the rear end on a jack with a person in each side but ended up using jack stands to hold it up. the rear end kept wanting to tip forward on the jack.
we got the DS control arm in the tabs and bolted no problem. the issue we had was on the PS. first, there was about a 1.5" distance that we had to account for to line up the arm w/ the tabs. then trying to get the bolt holes to line up was impossible. I ended up removing the bolt attaching the control arm to the axle, installing the arm to the frame, and then trying to reattach the arm back to the axle. we toyed with the idea of making a tapered bolt to hammer through the frame tabs to line things up, but then couldn't figure a way to get that bolt out since there's no room to hammer it back out from the inside of the frame.
anyway, everything worked out, just took a bit of thinking.

Not sure if I'll need a transmission jack for this build since it gets installed with the engine from above.


#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #213 of 263 (permalink) Old 05-20-2019, 04:43 PM
Senior Member
FFCars Craftsman

jhargrove's Avatar

Join Date: Feb 2018
Location: Aurora, Il
Posts: 691
"Not sure if I'll need a transmission jack for this build since it gets installed with the engine from above.[/QUOTE]"

I was referring to attaching the transmission to the engine before you install the drivetran in the chassis.

I already tried once to put the transmission on my engine and I could not make everything work quite right with a regular Jack and it was very awkward. The transmission Jack is way more stable so that you can do it by yourself if you need to. Just what I encountered so far.

Jason

Last edited by jhargrove; 05-20-2019 at 06:26 PM.
jhargrove is online now
Sponsored Links
Advertisement

post #214 of 263 (permalink) Old 06-01-2019, 09:20 PM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
Installed pan hard bar today. Hardware kit came with 4 0.375" spacers, 1 0.25"spacer, and 2 washers/ shims. I was able to get the PS attached to the shock mount as described in the manual with a shim on the rear side, and one 0.25"spacer and 0.375"x2 on the front. On the DS mount, I was only able to fit 0.375"x2 spacers on the front. There's no way to get the other shim in even with spreading the tabs. Any problems here?

Also drilled holes in DS footbox wall for brake lines. Apparently bought wrong grommets for this.

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #215 of 263 (permalink) Old 06-04-2019, 02:47 AM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
Working on gas tank tonight. Got the vent, fuel level sender, and filler neck gasket installed. Lubed up the o ring for the sender unit with some white lithium grease as recommended on another thread to prevent tearing of the o ring and subsequent leaking. Still need to purchase an in-tank fuel pump and install that before running fuel and return lines. Tank straps installed on the rear as well. The openings of the straps needed to be reshaped a bit to accept the bolt. I ended up tapping it with a 4 lb sledge until the opening became more round, rather than tear drop shaped. I also included pics of panhard bar. I was only able to fit 0.375"x2 spacers in front on the DS mount. There was no way the extra shim would have fit on the rear side of the bar.
Attached Images
File Type: jpg 20190603_215121_1559616389589.jpg (217.0 KB, 25 views)
File Type: jpg 20190603_215130_1559616406816.jpg (236.9 KB, 26 views)
File Type: jpg 20190603_215805_1559616426374.jpg (223.8 KB, 30 views)
File Type: jpg 20190603_215837_1559616445382.jpg (204.0 KB, 29 views)

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #216 of 263 (permalink) Old 06-04-2019, 11:59 AM
Senior Member

phileas_fogg's Avatar

Join Date: Jul 2014
Location: Fairfax Station, VA
Posts: 1,085
That bar doesn't look right to me (but I know next to nothing about the 3-link). Wouldn't the bracket press up against the side of the rod end & prevent it from moving the way it should? Seems like you should have a spacer on each side...

Hopefully someone with actual knowledge will weigh in.


John

MK IV Roadster #8631
Ford 302, Holley Terminator EFI, T5z, 3.55 Rear End, IRS, 17” Halibrand Replicas (9” front, 10.5” rear), Nitto 555 G2’s (275/40ZR17 front, 315/35ZR17 rear), Fast Freddie’s Power Steering, F5 Wilwood Brakes, FFMetal’s Firewall Forward, Forte’s Hydraulic Clutch & Throttle Linkage

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
phileas_fogg is offline
post #217 of 263 (permalink) Old 06-04-2019, 12:21 PM
Senior Member
FFCars Major

rich grsc's Avatar

Join Date: Aug 2007
Location: O'Fallon, Mo
Posts: 7,311
A shim one each side of the rod end. Ford recommends engine oil on the o-rings, use the same for the fill tube ring.
rich grsc is offline
post #218 of 263 (permalink) Old 06-04-2019, 01:16 PM
Not a waxer

JKleiner's Avatar

Join Date: Apr 2002
Location: Bloomington, Indiana
Posts: 11,415
As Rich said you need to have a spacer on each side rather than both on the same side. Looking at the photo it appears that you have the mount squeezed in a great deal...if you spread it when you reorient the spacers you might be able to fit the other shim in.

Jeff

Mk3 #5946 build pics w/text

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


Mk4 #7276 "indy14" Build thread

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


Mk4 Bodywork thread

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
JKleiner is online now
post #219 of 263 (permalink) Old 06-04-2019, 03:49 PM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
Quote:
Originally Posted by JKleiner View Post
As Rich said you need to have a spacer on each side rather than both on the same side. Looking at the photo it appears that you have the mount squeezed in a great deal...if you spread it when you reorient the spacers you might be able to fit the other shim in.

Jeff
I had to spread it to initially get the spacers in. I don't think i'd be able spread it enough to get a shim in as well, at least not without really deforming the tabs. I'll reposition the spacers so that there's one on either side of the bar. on the opposite side (PS), I followed the manual and put all the spacers on the front (0.375" x2 and 0.25"x1) with a washer/shim on the rear side of the bar. I'm assuming this is correct, right?

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #220 of 263 (permalink) Old 06-05-2019, 03:50 PM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
fuel system delivery

starting to consider fuel system at this point.
planning on using intank pump and either Holley or FiTech EFI.
I'm running a 289 K code SBF engine, so ~300hp.
after doing some research, i'll likely get a stock fuel pump bracket for my gas tank and either a 155-190LPH pump. Seems like enough for my engine requirements.
Do I need a specific fuel filter before my EFI or will the stock filter provided in complete kit be sufficient?


#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #221 of 263 (permalink) Old 06-05-2019, 09:43 PM
Senior Member

phileas_fogg's Avatar

Join Date: Jul 2014
Location: Fairfax Station, VA
Posts: 1,085
Quote:
Originally Posted by egchewy View Post
...Do I need a specific fuel filter before my EFI or will the stock filter provided in complete kit be sufficient?
Read the documentation for the two EFI systems under consideration; they will each have a spec (my Holley Terminator requires a 10u filter). Then compare the spec to the one for your fuel filter (for my kit, F5 provided a 15u filter). Then you'll know.

If you find that you have to replace the filter, then you have some choices based on your fuel lines. If you use the 5/16" feed and 1/4" return, you can buy a filter with 5/16" in/out quick connects & use the F5-provided hose & fittings. If you upgrade the hard lines to 3/8" feed & return (in anticipation of later upgrading the motor such that it needs them), you have more components to buy. I recommend calling Mark at Breeze Automotive & discussing your options if you go the 3/8" route. (You'll probably want to call him any way when you start figuring out the engine compartment plumbing & how to get from your hard lines to AN6 soft lines.)

For more ideas (& the long version of this story), take a look at https://thefactoryfiveforum.com/show...nk-fuel-system.


John

NOTE: The Wix 33097 is a 10u filter with 5/16" in/out quick connects.

MK IV Roadster #8631
Ford 302, Holley Terminator EFI, T5z, 3.55 Rear End, IRS, 17” Halibrand Replicas (9” front, 10.5” rear), Nitto 555 G2’s (275/40ZR17 front, 315/35ZR17 rear), Fast Freddie’s Power Steering, F5 Wilwood Brakes, FFMetal’s Firewall Forward, Forte’s Hydraulic Clutch & Throttle Linkage

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

Last edited by phileas_fogg; 06-05-2019 at 09:59 PM.
phileas_fogg is offline
post #222 of 263 (permalink) Old 06-13-2019, 11:46 PM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
Back from vaca and finally getting brake reservoirs buttoned up. I was waiting on my grommets to arrive. If anyone is wondering what size, make sure you get the ones that are 1/4" thick to get through the thick footbox wall. Reinstalled reservoir bracket. Placed a split piece of fuel line to protect hard brake lines from touching the bolts/ nuts from my bracket. Received my Fitech EFI while I was gone too. Rear brake calipers coming tomorrow. I'll post under My previous post more additional details. Does anyone know the supplied fuel filter micron size that comes with the complete kit?
Attached Images
File Type: jpg 20190613_181302.jpg (242.3 KB, 28 views)
File Type: jpg 20190613_181314.jpg (240.2 KB, 28 views)
File Type: jpg 20190613_182611.jpg (232.9 KB, 27 views)

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box

Last edited by egchewy; 06-14-2019 at 12:49 AM.
egchewy is online now
post #223 of 263 (permalink) Old 06-14-2019, 12:43 AM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
Rear caliper update

Quote:
Originally Posted by egchewy View Post
I also emailed Jay from FFR. My rear calipers have been on back order since I received my kit in Jan. Apparently, the vendor they were working with who provided the rear calipers for the rear brake kit (not wilwood) was supposed to have a shipment in at the end of 2018. They missed that shipment and have stopped taking FFR's phone calls. FFR is working with a new vendor now and they hope to have a product in the next month or so. The problem is that they need to make the brackets fit both 11.65" and 13" rotors, so once they get a sample caliper in, they need a couple of months to mock up new brackets and manufacture them. So they offered me a few options: 1) wait on new calipers and brackets to arrive, 2) send out 87-88' Tbird turbo couple calipers and brackets, but I would need to grind off the part of the bracket that interferes w/ the rotors, or 3) get a full refund on the rear brake kit and source my own rear calipers.

Any thoughts/suggestions? I wasn't sure how the FFR rear brake kit calipers were different from the Tbird calipers. Do the pads sent to me fit ? Do the brackets fit the existing caliper axle brackets?
Update in rear calipers. Got a call for Jay this week. New calipers are still months away. They've received prototypes but still months away from production of new castings. FFR has a number of reconditioned T bird calipers that they are sending out to those waiting, but only 20pair or so. I've elected to go forward with these as I'm waiting on these before finalizing rear brake lines. I'm assuming you'll get a call if you've been waiting to give you the option.

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #224 of 263 (permalink) Old 06-15-2019, 07:13 PM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
Painting rear calipers and stripping paint off engine block. So many nooks and crannies on the engine. Pretty neat to see the original casting marks from 50+ yrs ago.
Attached Images
File Type: jpg 20190615_143531_1560625992367.jpg (223.3 KB, 37 views)
File Type: jpg 20190615_145833_1560626009917.jpg (227.6 KB, 34 views)

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #225 of 263 (permalink) Old 06-18-2019, 09:50 PM
Junior Charter Member

Foster's FFR's Avatar

Join Date: Jan 2007
Location: Lowell, MA
Posts: 381
Quote:
Originally Posted by egchewy View Post
Pretty neat to see the original casting marks from 50+ yrs ago.
That's very cool. I just figured out how to get the Ford 5.0 HO badge off the top of the intake manifold so I could access what I assumed were two hidden bolts. They were there. My sons find the engine tear down at least as interesting as I do. We haven't cleaned off enough junk to find the casting marks yet - it's still covered with half eaten nuts and shed snake skin, the later of which we took as a good omen.

Foster
Toadster thanked this.

#9592 MKIV Complete Kit
1990 302 Lincoln Mark VII donor
Tremec T5
8.8 Ford w/ 4.10 gears
Manual steering & brakes
Build Thread -
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Foster's FFR is online now
post #226 of 263 (permalink) Old 06-18-2019, 09:56 PM
Senior Member
FFCars Craftsman

jhargrove's Avatar

Join Date: Feb 2018
Location: Aurora, Il
Posts: 691
Good job Chewy. If I can help at all let me know. I may be able to relay some of my lessons learned. As far as I can tell SBF is all relatively the same until the intake.

The tear down process for me was the most educational thing I did. Go slow take pics. Learn.

Here is a before and after of my engine build.

DSS Racing I thought was a great vender and will help you through any process. They will help you buy anything you need. They helped me plan the whole engine out
They made sure what I was doing all worked together and made sense for my application. They are out of St. Charles il but there business is based on mail order. They specialize in Mustangs they are well known.

Jason
Attached Images
File Type: jpg 20180126_134926_1560894910821.jpg (232.0 KB, 25 views)
File Type: jpg 20190607_141103_1560894947280.jpg (263.8 KB, 30 views)

Last edited by jhargrove; 06-18-2019 at 10:08 PM.
jhargrove is online now
post #227 of 263 (permalink) Old 06-18-2019, 10:35 PM
Junior Charter Member

Foster's FFR's Avatar

Join Date: Jan 2007
Location: Lowell, MA
Posts: 381
Wow

That's a great looking engine Jason! Gives me hope for the old 302 I've started in on. She's in need of some cosmetic repair, but I'm hopeful that the internals are good.

Foster
Attached Images
File Type: jpg Ford 5.0 HO.jpg (212.3 KB, 22 views)

#9592 MKIV Complete Kit
1990 302 Lincoln Mark VII donor
Tremec T5
8.8 Ford w/ 4.10 gears
Manual steering & brakes
Build Thread -
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Foster's FFR is online now
post #228 of 263 (permalink) Old 06-19-2019, 08:06 AM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
Engine tear down scheduled for next weekend. Planning on LCS this weekend with a friend to get some ideas and to meet many of the people who've helped me along the way. Look for me and my buddy in his bright blue (Porsche Mexico blue) cobra with red fender stripes (sans hood stripes).

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #229 of 263 (permalink) Old 06-21-2019, 01:54 AM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
Need help with rear brake pads. Are these wires/ springs supposed to push through the caliper and snap in place? I can't see how you can get both wires through the gap in the caliper. I'm having a heck of a time trying to get the second pad in. Can I just remove the wire?
Attached Images
File Type: jpg 20190620_202906_1561081989143.jpg (259.7 KB, 20 views)
File Type: jpg 20190620_202910_1561082006969.jpg (243.2 KB, 21 views)

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #230 of 263 (permalink) Old 06-21-2019, 12:08 PM
Senior Member

phileas_fogg's Avatar

Join Date: Jul 2014
Location: Fairfax Station, VA
Posts: 1,085
Don't cut the wires. They're actually springs that go inside the brake housing & keep the pads from moving around vertically. You want both springs inside the housing, and the opposite end of the pad hooks under some tabs on the housing. It takes some fiddling, but you'll get it.


John

MK IV Roadster #8631
Ford 302, Holley Terminator EFI, T5z, 3.55 Rear End, IRS, 17” Halibrand Replicas (9” front, 10.5” rear), Nitto 555 G2’s (275/40ZR17 front, 315/35ZR17 rear), Fast Freddie’s Power Steering, F5 Wilwood Brakes, FFMetal’s Firewall Forward, Forte’s Hydraulic Clutch & Throttle Linkage

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
phileas_fogg is offline
post #231 of 263 (permalink) Old 06-21-2019, 12:21 PM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
Quote:
Originally Posted by phileas_fogg View Post
Don't cut the wires. They're actually springs that go inside the brake housing & keep the pads from moving around vertically. You want both springs inside the housing, and the opposite end of the pad hooks under some tabs on the housing. It takes some fiddling, but you'll get it.


John
I finally figured it out this morning before work. I figured out that you don't need the metal clips that come with the calipers. the metal wires/springs act as the tension that holds everything in place.

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #232 of 263 (permalink) Old 06-21-2019, 04:52 PM
Senior Member
FFCars Craftsman

beeman's Avatar

Join Date: Nov 2007
Location: NE Indiana
Posts: 1,389
Quote:
Originally Posted by egchewy View Post
Engine tear down scheduled for next weekend. Planning on LCS this weekend with a friend to get some ideas and to meet many of the people who've helped me along the way. Look for me and my buddy in his bright blue (Porsche Mexico blue) cobra with red fender stripes (sans hood stripes).
Getting ready to head out, see you soon!

egchewy thanked this.

MK3.1 2004 Mach 1 donor. PS, PB, ABS, TC.
GTM #304 525hp LPE LS3
2000 C5 Coupe 489HP LPE LS1
beeman is offline
post #233 of 263 (permalink) Old 06-25-2019, 03:57 AM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
Rear calipers are in finally. Painted, reassembled, and attached. No shims needed for my brakes. Bent rear hard brake line as well. Need to buy another shorter length to bring hard lines from DS to PS. Ordering fuel pump, fittings, and filter from Forte soon as well as clutch.
Attached Images
File Type: jpg 20190624_214421_1561434864552.jpg (224.7 KB, 25 views)
File Type: jpg 20190624_232049_1561434882770.jpg (216.9 KB, 25 views)
File Type: jpg 20190624_232037_1561434901571.jpg (214.1 KB, 23 views)

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #234 of 263 (permalink) Old 06-25-2019, 04:12 AM
Senior Member
FFCars Craftsman

jhargrove's Avatar

Join Date: Feb 2018
Location: Aurora, Il
Posts: 691
Quote:
Originally Posted by egchewy View Post
Rear calipers are in finally. Painted, reassembled, and attached. No shims needed for my brakes. Bent rear hard brake line as well. Need to buy another shorter length to bring hard lines from DS to PS. Ordering fuel pump, fittings, and filter from Forte soon as well as clutch.
Awesome!
jhargrove is online now
post #235 of 263 (permalink) Old 06-25-2019, 12:00 PM
Senior Member
FFCars Major

rich grsc's Avatar

Join Date: Aug 2007
Location: O'Fallon, Mo
Posts: 7,311
A little advice, get rid of the brake line with all the loops in it. It's just a place for air bubbles to get trapped and make bleeding the brakes a pain. Always make the lines the correct length, looks better and less of a problem.
egchewy thanked this.
rich grsc is offline
post #236 of 263 (permalink) Old 06-30-2019, 10:51 PM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
Engine tear down today! I received this engine from a buddy of mine who bought it for his build but decided to go another direction. It's a 1966 289 HiPo 30 over that was reportedly rebuilt by a previous owner. The engine has been sitting for at least 5 yrs by my and my friend's estimate. Not well versed on engines, so I had another friend help me take it apart to look at everything and to replace all the gaskets. We found all new parts, roller rockers, and clean cylinders without any rust or scale. I'm working on cleaning all surfaces and going to get the heads checked at a machine shop as some of the rocker springs were sitting compressed all this time.
Attached Images
File Type: jpg 20190630_131842_1561935016671.jpg (246.1 KB, 22 views)
File Type: jpg 20190630_152001_1561935033506.jpg (237.8 KB, 23 views)
File Type: jpg 20190630_152007_1561935051862.jpg (245.5 KB, 23 views)
File Type: jpg 20190630_152638_1561935080303.jpg (231.7 KB, 21 views)

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
post #237 of 263 (permalink) Old 07-01-2019, 11:27 AM
FFCobra Craftsman

CraigS's Avatar

Join Date: Feb 2005
Location: Blacksburg, Va
Posts: 21,773
The engine looks great.

FFR 5353K, 408W, TKO 500, 2015 IRS w/ 315 gear, Breeze QA1 DA coilovers front and rear, APE hardtop, Forte front swaybar
CraigS is offline
post #238 of 263 (permalink) Old 07-01-2019, 01:51 PM
Senior Member
FFCars Craftsman

jhargrove's Avatar

Join Date: Feb 2018
Location: Aurora, Il
Posts: 691
Any parts you might need let me know. They are just sitting here. Including working heads. Everything just needs cleaned.
jhargrove is online now
post #239 of 263 (permalink) Old 07-01-2019, 02:57 PM
Not a waxer

JKleiner's Avatar

Join Date: Apr 2002
Location: Bloomington, Indiana
Posts: 11,415
Clearly that engine has never been fired. Since neither you nor the friend you got it from have no first hand experience with it or knowledge the build I would be inclined to take it all the way apart, check all measurements, verify piston to valve, etc. then if it all looks good reassemble it.

Good luck and keep us updated!

Jeff

Mk3 #5946 build pics w/text

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


Mk4 #7276 "indy14" Build thread

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


Mk4 Bodywork thread

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
JKleiner is online now
post #240 of 263 (permalink) Old 07-01-2019, 04:29 PM Thread Starter
Senior Member

egchewy's Avatar

Join Date: Nov 2011
Location: Dublin. OH
Posts: 283
my friend who's helping me take it apart has pretty extensive engine and racing knowledge. he's more of a chevy guy, but i'll forgive him

Quote:
Originally Posted by JKleiner View Post
Clearly that engine has never been fired. Since neither you nor the friend you got it from have no first hand experience with it or knowledge the build I would be inclined to take it all the way apart, check all measurements, verify piston to valve, etc. then if it all looks good reassemble it.

Good luck and keep us updated!

Jeff

#9503 MK4 complete kit
1966 289 SBF HiPo bored 30 over
Tremec T5Z
8.8" Moser rear end w/ 3.55 gear ratio
manual steering
RT drop trunk
Breeze front battery box
egchewy is online now
Sponsored Links
Advertisement

Reply

Bookmarks

Quick Reply
Message:
Options

Register Now



In order to be able to post messages on the FFCars.com : Factory Five Racing Discussion Forum forums, you must first register.
Please enter your desired user name, your email address and other required details in the form below.

User Name:
Password
Please enter a password for your user account. Note that passwords are case-sensitive.

Password:


Confirm Password:
Email Address
Please enter a valid email address for yourself.

Email Address:
OR

Log-in











Currently Active Users Viewing This Thread: 1 (0 members and 1 guests)

Thread Tools
Show Printable Version Show Printable Version
Email this Page Email this Page
Display Modes
Linear Mode Linear Mode



Similar Threads
Thread Thread Starter Forum Replies Last Post
Shark92651's MK4 Coyote Build #9327 shark92651 Ford Modular Engine Roadster Builds 202 Today 01:14 PM
FFR 9457 Roadster build thread sdonnel Factory Five Roadsters 23 05-31-2019 02:10 PM
Build School jhargrove Factory Five Roadsters 19 02-03-2019 11:18 AM
new roadster build egchewy New Member Introductions 6 01-29-2019 10:56 AM
FFR 9439 Roadster Build Status dwleo Factory Five Roadsters 0 12-18-2018 03:40 PM

Posting Rules
You may post new threads
You may post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are On
Pingbacks are On
Refbacks are On


For the best viewing experience please update your browser to Google Chrome



Welcome to FFCars! The representations expressed are the representations and opinions of the FFCars.com forum members and do not necessarily reflect the opinions and viewpoints of the site owners, moderators, Factory Five Racing, Inc. or Ford Motor Company. This website has been planned and developed by FFCars.com and its forum members and should not be construed as being endorsed by Factory Five Racing, Inc. or Ford Motor Company for any purpose. "FFR", "Factory Five", "Factory Five Racing", and the Factory Five Racing logo are registered trademarks of Factory Five Racing, Inc. FFCars.com forum members agree not to post any copyrighted material unless the copyrighted material is owned by you. Although we do not and cannot review the messages posted and are not responsible for the content of any of these messages, we reserve the right to delete any message for any reason whatsoever. You remain solely responsible for the content of your messages, and you agree to indemnify and hold us harmless with respect to any claim based upon transmission of your message(s). Thank you for visiting the FFCars.com Forum dedicated to Factory Five.
